Study Plan
A fully quarter scaled plan set of the elevations and floor plan fully dimensioned as it was designed. Below are the 4 top uses of the Scaled Study Plan Set:
-
Funding & Underwriting Optimization
Instantly supplies commercial loan officers and appraisers with the exact dimensional baselines required to initiate construction loan financing.
-
Absolute Site & Land Compatibility
Allows you and your excavator to physically map the home’s real footprint against your property lines, grading, acreage characteristics, and topography.
-
HOA & Community Acceptance
Provides the architectural review board of your local community or subdivision with the authentic configuration layout they require for early phase structural approval.
-
Local Building Code & Regulatory Validation
Equips you to review zoning, setbacks, and high-load regional environmental constraints directly with county building departments before investing in blueprints.
Plan details
| Project Type | Framed |
|---|---|
| Home Style | Shade Structures |
| Bedrooms | 0 |
| Bathrooms | 0 |
| Stories | 0 |
| Main Sq Ft | 100 |
| Loft Sq Ft | 0 |
| Basement Sq Ft | 0 |
| Total Sq Ft | 0 |
| Garage | — |
| Basement | — |
| Reference | arches |
About this plan
The "Arches" pergola model is a dramatic 2 level pergola This model uses a double 2x for the main headers. You can completely configure the size (100 sq ft to 384 sq ft), parts, color & PRICE by going to our shade configurator for the Arches: https://sierralogandtimber.com/arches/
The configurator will enable you to view and manipulate in 3D, configure the size from 10x10 to 16x24, with multiple size parts and frequency to choose from, it will display in realtime the price, and provides augmented reality so you can actually place in your yard with the color of your choice...its amazing!
If the configurator cann't create what you want, call us and we will design what you want for FREE!
The Red Cedar parts package includes: (create price by using the configurator)
- all the Red Cedar wood parts
- all the Simpson "Outdoor Hardware"
- all the fasteners
- pre-stained with the Ready Seal color of your choice
If you need any help or if you create a price, call the office for the current discount.
Below is a screenshot of the configurator
